Supply voltage                                15 - 32VDC (Nom .: 27VDC)
Power consumption when inactive, non-communicated <160μA @ 27VDC
Power consumption when inactive, communicative <200μA @ 27VDC
Power consumption when in alarm, communicated 6.5mA
Maximum current in RI terminal in the event of an alarm (terminals 4/1) 7.5mA (max) / 7.5V
Connection conductors                   0.4mm² - 2.0mm²
Working temperature                      -10 ° C to + 60 ° C
Degree of protection                        IP30
Weight (based on)                          ~ 125g
Dimensions (with base)                  103x42mm
